The Vickers Wellington was a British twin-engined, long-range medium bomber. It was designed during the mid-1930s at Brooklands in Weybridge, Surrey, led by Vickers-Armstrongs’ Chief Designer Rex Pierson; a key feature of the aircraft is its geodesic fuselage structure, principally designed by Barnes Wallis. Development had been started in response to Air Ministry Specification B.9/32; issued in the middle of 1932, this called for a twin-engined day bomber capable of delivering higher performance than any previous design. Other aircraft developed to the same specification include the Armstrong Whitworth Whitley and the Handley Page Hampden. During the development process, performance requirements such as for the tare weight changed substantially, as well as the powerplant for the type being swapped.
The Wellington was widely used as a night bomber in the early years of the Second World War, performing as one of the principal bombers used by Bomber Command. During 1943, it started to be superseded as a bomber by the larger four-engined “heavies” such as the Avro Lancaster. The Wellington continued to serve throughout the war in other duties, particularly as an anti-submarine aircraft. It holds the distinction of being the only British bomber to be produced for the duration of the war and of being produced in a greater quantity than any other British-built bomber. The Wellington remained as first-line equipment when the war ended, although it had been increasing relegated to secondary roles. The Wellington was one of two bombers named after Arthur Wellesley, 1st Duke of Wellington, the other being the Vickers Wellesley.
A larger heavy bomber aircraft designed to Specification B.1/35, the Vickers Warwick, was developed in parallel with the Wellington; the two aircraft shared around 85% of their structural components. Many elements of the Wellington were also reused in a civil derivative, the Vickers VC.1 Viking.
In October 1932, the British Air Ministry invited Vickers to tender for the recently issued Specification B.9/32, which sought a twin-engine medium daylight bomber. In response, Vickers conducted a design study, led by Chief Designer Rex Pierson Early on, Vickers’ chief structures designer Barnes Wallis proposed the use of a geodesic airframe, inspired by his previous work on airships and the single-engined Wellesley light bomber. During structural testing performed at the Royal Aircraft Establishment, Farnborough, the proposed structure demonstrated not only the required strength factor of six, but reached 11 without any sign of failure, providing the geodesic airframe to possess a strength far in excess of normal levels. This strength allowed for the structure design to be further developed to reduce the size of individual members and adopt simplified standard sections of lighter construction.
Vickers studied and compared the performance of various air and liquid-cooled engines to power the bomber, including the Bristol Pegasus IS2, Pegasus IIS2, the Armstrong Siddeley Tiger, and the Rolls-Royce Goshawk I. The Pegasus was selected as the engine for air-cooled versions of the bomber, while the Goshawk engine was chosen for the liquid-cooled engine variant. On 28th February 1933, two versions of the aircraft, one with each of the selected powerplants, were submitted to the tender. In September 1933, the Air Ministry issued a pilot contract for the Goshawk-powered version. In August 1934, Vickers proposed to use either the Pegasus or Bristol Perseus engines instead of Goshawk, which promised improvements in speed, climb rate, ceiling, and single-engine flight capabilities without any major increase in all-up weight; the Air Ministry accepted the proposed changes.
Other refinements of the design had also been implemented and approved, such as the adoption of variable-pitch propellers, and the use of Vickers-produced gun turrets in the nose and tail positions. By December 1936, the specification had been revised to include front, rear, and midship wind-protected turret mountings. Other specification changes included modified bomb undershields and the inclusion of spring-loaded bomb bay doors. The proposal had also been developed further, a mid-wing arrangement was adopted instead of a shoulder-mounted wing for greater pilot visibility during formation flight and improved aerodynamic performance, as well as a substantially increased overall weight of the aircraft. Design studies were also conducted on behalf of the Air Ministry into the adoption of the Rolls-Royce Merlin engine.
In spite of a traditional preference of the establishment to strictly adhere to the restrictive tare weight for the aircraft established in the tender, both Pierson and Wallis firmly believed that their design should adopt the most powerful engine available. Perhaps in response to pressure from Vickers, the Air Ministry overlooked, if not openly accepted, the removal of the tare weight restriction, as between the submission of the tender in 1933 and the flight of the first prototype in 1936, the tare weight eventually rose from 6,300lb to 11,508lb. The prescribed bomb load and range requirements were routinely revised upwards by the Air Ministry; by November 1935, figures within the Ministry were interested in the possibility of operating the aircraft at an all-up weight of 30,500lb, which aviation author C.F. Andrews stated to be “a very high figure for a medium bomber of those days”.
During the development phase of the aircraft, the political and military situations in Europe drastically transformed. With the rise of fascist dictatorships in Germany and Italy, the British government had become keen to reevaluate the capabilities of the nation’s armed forces, including the Royal Air Force . By 1936, the need for a high priority to be placed on the creation of a large bomber force, which would form the spearhead of British offensive power, had been recognised; accordingly, a new command organisation within the RAF, Bomber Command, was formed that year to deliver upon this requirement.
In early 1936, an initial prototype, K4049, which was originally designated as a Type 271, was assembled. The prototype could accommodate a payload of nine 250lb or 500lb bombs, and both nose and tail gun positions were fitted with hand-operated turrets furnished with a single gun in each, provisions for a third retractable gun in a dorsal position were also present. It had provisions for a crew of four, along with a fifth position for performing special duties.
On 15th June 1936, K4049 conducted its maiden flight from Brooklands. Vickers chief test pilot Joseph Summers flew K4049 on its first flight, accompanied by Wallis and Trevor Westbrook. The aircraft soon came to be largely regarded as being an advanced design for its era and proved to have considerable merit during its flight trials. In April 1937, K4049 was destroyed by an accident during a service test flight. The cause was the failure of the elevator’s horn balance due to excessive slipstream exposure, leading to the aircraft inverting and rapidly descending into terrain. It was completely destroyed in the crash, which also had resulted in the death of the navigator. The horn balances would later be deleted, and thus not feature on production aircraft.
On 5th June 1936, the name Crecy was initially chosen for the type, and it was publicly displayed as such. On 15th August 1936, the aircraft was accepted for production. On 8th September 1936, the name Wellington was adopted for the type; Pierson later explained that this was due to Air Ministry nomenclature and also followed the tradition set by the Vickers Wellesley of possessing names referring back to the Duke of Wellington. On 12th December 1936, a corresponding works order was issued for the Wellington.
In addition to the prototype, refinement of the Wellington’s design was influenced by the issuing of Specifications B.1/35 and B.1/35, the latter of which had led to the parallel development of a larger bomber aircraft, the Vickers Warwick. According to Andrews, the Wellington was practically redesigned to form the first production model of the aircraft, during which extensive details attributed to the Warwick were added, such as the deepening of the fuselage, the lengthening of the nose, a reshaped horizontal tail unit, and an increased crew complement for four to five members. Other changes made included the adoption of a retractable tailwheel and constant-speed propellers; the Air Ministry also requested the adoption of a Nash & Thompson-design ventral turret in place of the Vickers design.
On 23rd December 1937, the first production Wellington Mk I, L4212, conducted its first flight; L4212 subsequently participated in an intensive flight program. Flight trials with L4212 confirmed the aerodynamic stability initially encountered by K4049, but also revealed the aircraft to be nose-heavy during dives, which was attributed to the redesigned elevator. Accordingly, modifications, including the interlinked of the flaps and the elevator trim tabs, were successfully trialled on L4212 to resolve the issue.
In August 1936, an initial order for 180 Wellington Mk I aircraft, powered by a pair of 1,050 hp (780 kW) Bristol Pegasus radial engines, was received by Vickers; it had been placed so rapidly that the order occurred prior to the first meeting intended to decide the details of the production aircraft. In October 1937, another order for a further 100 Wellington Mk Is, produced by the Gloster Aircraft Company, was issued; it was followed by an order for 100 Wellington Mk II aircraft, which were instead powered by a pair of Rolls-Royce Merlin X V12 engines. Yet another order was placed for 64 Wellingtons produced by Armstrong Whitworth Aircraft. With this flurry of order and production having been assured by the end of 1937, Vickers set about simplifying the manufacturing process of the aircraft and announced a target of building one Wellington per day.
Construction took longer to build due to the geodesic fuselage in comparison to other designs using monocoque approach, leading to criticism of the Wellington. In particular, it was difficult to cut holes in the fuselage for access or equipment fixtures; to aid manufacturing, the Leigh light was deployed through the mounting for the absent FN9 ventral turret. In the late 1930s, Vickers built Wellingtons at a rate of one per day at Weybridge and 50 a month at Broughton in North Wales. Many of the employees on the production lines were only semi-skilled and new to aircraft construction. Peak wartime production in 1942 saw monthly rates of 70 at Weybridge, 130 at Broughton and 102 at Blackpool. Shadow factories were set up to produce parts for the Wellington all over the British Isles.
In October 1943, as a propaganda and morale-boosting exercise, workers at Broughton gave up their weekend to build Wellington number LN514 rushed by the clock. The bomber was assembled in 23 hours 50 minutes, and took off after 24 hours 48 minutes, beating the record of 48 hours set by a factory in California. Each Wellington was usually built within 60 hours. It was filmed for the Ministry of Information for a newsreel Worker’s Week-End, and was broadcast in both Britain and America. It was the first time in the world that a British aircraft manufacturer had attempted such a feat with a metal aircraft of this scale.
A total of 180 Wellington Mk I aircraft were built; 150 for the RAF and 30 for the Royal New Zealand Air Force (RNZAF) (which were transferred to the RAF on the outbreak of war and used by 75 Squadron). In October 1938, the Mk I entered service with 9 Squadron. The Wellington was initially outnumbered by the Handley Page Hampden (also ordered by the Ministry to B.9/32) and the Armstrong Whitworth Whitley (to B.34/3 for a ‘night’ bomber) but outlasted both rival aircraft in service. The Wellington went on to be built in 16 separate variants, in addition to two training conversions after the war. The number of Wellingtons built totalled 11,461 of all versions, a greater quantity produced than any other British bomber. On 13th October 1945, the last Wellington to be produced rolled out.
The Wellington Mk I was quickly superseded by several successive variants featuring various improvements. Improvements to the turrets and the strengthening of the undercarriage quickly resulted in the Wellington Mk IA. According to Andrews, the IA model bore more similarities to the later Wellington Mk II than to its Mk I predecessor. Due to armament difficulties encountered that left the Wellington with weaker than intended defences, the Wellington Mk IB was proposed for trials, but appears to have been unbuilt. Further development of various aspects of the aircraft, such as the hydraulics and electrical systems, along with a revision of the ventral turret gun, led to the Wellington Mk IC.
In January 1938, design work on what would become the Wellington Mk II formally commenced. The principal change on this model was the adoption of the Merlin engine in place of the Pegasus XVIII; other modifications included hydraulic and oxygen system revisions along with the installation of cabin heating and an astrodome. On 3rd March 1939, L4250, the prototype Mk II, performed its maiden flight; this had been delayed due to production delays of its Merlin X engines. Stability and balance issues were encountered during flight tests of the prototype, resulting in further changes such as the enlargement of the tailplane. By late 1939, the Mk II was capable of delivering superior performance to the Mk IC, such as higher cruising and top speeds, increased all-up weight or alternatively greater range, and a raised ceiling.
The Vickers Wellington was a twin-engined long-range medium bomber, initially powered by a pair of Bristol Pegasus radial engines, which drove a pair of de Havilland two-pitch propellers. Various different engines and propeller configurations were used on different variants of the aircraft, which included several models of both the Bristol Hercules and the iconic Rolls-Royce Merlin engines. Recognisable characteristics of the Wellington include the high aspect ratio of its tapered wing, the depth of its fuselage, and the use of a tall single vertical stabiliser on its tail unit, which reportedly aided in recognition of the type.
The Wellington typically had a crew of five. The bomb-aimer was located within the aircraft’s nose. The Wellington could be fitted with dual flight controls, and specialised dual-control conversion sets were developed for the purpose of performing training upon the type. The cockpit also contained provisions for heating and de-iceing equipment, which was introduced on later models of the Wellington. The Wellington Mk I had a maximum offensive bomb load of 4,500 lb (2,000 kg), more than one-fifth of the overall aircraft’s 21,000 lb (9,500 kg) all-up weight. Additional munitions and an expanded bombing capacity were a recurring change made in many of the subsequent variants of the Wellington developed during the war, including the carrying of ever-larger bombs.
On 3 September 1939, the eve of the outbreak of the Second World War, No. 3 Group of Bomber Command comprised eight squadrons (No. 9, No. 37, No. 37 No. 38, No. 99, No. 115 and No. 149 Squadrons), alongside two reserve squadrons (No. 214 and No. 215 squadrons), that were equipped with a mixture of Wellington Mk I and Mk IA aircraft.
On 4th September 1939, less than 24 hours after the commencement of hostility, a total of 14 Wellingtons of No. 9 and No. 149 Squadrons, alongside a number of Bristol Blenheim aircraft, performed the first RAF bombing raid of the war, targeting German shipping at Brunsbüttel. The bombing of the harbour itself had not been permitted by the Chamberlain War Cabinet for fear of injuring civilians. The effectiveness of the raid was diminished by a combination of poor weather and high amounts of anti-aircraft fire. During this opening raid, a pair of Wellingtons became the first aircraft to be lost on the Western Front.
On 3rd December 1939, 24 Wellingtons of No. 38, No. 115 and No. 147 Squadrons attacked the German fleet moored at Heligoland. The bombing commenced from high altitude and, while results of the bombing itself proved negligible in terms of damage, the ability of a formation of Wellingtons to adequately penetrate strongly defended hostile airspace was validated. On 14th December 1939, 12 Wellingtons of No. 99 Squadron conducted a low-level raid upon German shipping at the Schillig Roads and Wilhelmshaven. Encountering enemy fire from warships, flak, and Luftwaffe aircraft, the Wellington formation lost five aircraft, along with another that crashed near its base, while only one enemy fighter was downed.
On 18th December 1939, 24 Wellingtons of No. 9, No. 37 and No. 149 Squadrons participated in the Battle of the Heligoland Bight against the German fleet and naval bases in both the Schillig Roads and Wilhelmshaven. The Wellingtons were unable to deploy their bombs as all vessels were in harbour, thus restrictions on endangering civilians prevented their engagement. Having been alerted by radar, Luftwaffe fighter aircraft intercepted the incoming bombers near to Heligoland and continuously attacked the formation much of the way home. In total, 12 of the bombers were destroyed and a further three were badly damaged, defensive fire from the turrets downed four aircraft.
The action at Heligoland highlighted the Wellington’s vulnerability to attacking fighters, possessing neither self-sealing fuel tanks nor sufficient defensive armament. In particular, while the nose and tail turrets protected against attacks from the front and rear, the Wellington had no defences against attacks from the beam and above, as it had not been believed that such attacks were possible owing to the high speed of aircraft involved. As a consequence of the losses taken, the tactic of unescorted day bombing was abandoned, and Bomber Command decided to use the Wellington force to attack German communications and industrial targets instead.
Another key decision made was to switch the Wellington to night operations; on 25th August 1940, the type participated in the first night raid on Berlin. During the First 1,000 bomber raid on Cologne, conducted on 30th May 1942, 599 out of 1,046 RAF aircraft dispatched were Wellingtons; of these, 101 were flown by Polish aircrews. During operations under Bomber Command, Wellingtons flew a total of 47,409 operations, dropped 41,823 tons (37,941 tonnes) of bombs and lost 1,332 aircraft in action.
In one high-profile incident, a German Bf 110 night-fighter attacked a Wellington returning from an attack on Münster, causing a fire at the rear of the starboard engine. Co-pilot Sergeant James Allen Ward climbed out of the fuselage, kicked holes in the doped fabric of the wing for foot and hand holds to reach the starboard engine and smothered the burning upper wing covering. He and the aircraft returned home safely and Ward was awarded the Victoria Cross.
The Wellington was also adopted by Coastal Command, in which it contributed to the Battle of the Atlantic. It was used to carry out anti-submarine duties; on 6th July 1942, a Wellington sank its first enemy vessel. Specialised DWI variants were developed fitted with a 48 ft (14.63 m) diameter metal hoop were used for exploding enemy mines by generating a powerful magnetic field as it passed over them. In 1944, Wellingtons of Coastal Command were deployed to Greece and performed various support duties during the British intervention in the Greek Civil War. A few Wellingtons were operated by the Hellenic Air Force.
While the Wellington was superseded in the European Theatre, it remained in operational service for much of the war in the Middle East and in 1942, Wellingtons based in India became the RAF’s first long-range bomber operating in the Far East. It was particularly effective with the South African Air Force in North Africa. The Wellington also served in anti-submarine duties with 26 Squadron SAAF based in Takoradi, Gold Coast (now Ghana).
In late 1944, a radar-equipped Wellington XIV from 407 Sqn. RCAF was modified for use by the RAF’s Fighter Interception Unit as what would now be described as an airborne early warning and control aircraft. It operated at an altitude of 4,000 ft (1,219 m) over the North Sea to control a de Havilland Mosquito and a Bristol Beaufighter fighter intercepting Heinkel He 111 bombers flying from Dutch airbases and carrying out airborne launches of the V-1 flying bomb. The FIU operators on the Wellington would search for the He-111 aircraft climbing to launch altitude, then direct the Beaufighter to the bomber, while the Mosquito would attempt to intercept the V-1 if launched.
The Wellington is listed in the appendix to the novel KG 200 as one flown by the German secret operations unit KG 200, which also tested, evaluated and sometimes clandestinely operated captured enemy aircraft during the Second World War.
Corgi New Catalogue 2017
Corgi have released their latest Vickers Wellington in the New 2017 Corgi Catalogue. Always popular this is very likely to sell out before it is delivered to retailers. To avoid missing out please pre-order through Flying Tigers . Don’t forget NO DEPOSIT necessary and NO PAYMENT taken until your model is available to send to you.
The Wellington bomber proved to be an incredibly important aircraft in the history of the Royal New Zealand Air Force. Determined to modernise their force, they undertook a hugely expensive programme to build three new airfields and equip them with modern aircraft – 30 Vickers Wellington Mk.IC bombers ordered in 1938. Crews would be sent to England for training, before flying their aircraft back to New Zealand and their newly constructed bases. As the crews neared the end of their training, it became clear that war in Europe was inevitable and the New Zealand government gifted the aircraft and their crews to the RAF, in order to help in the war effort. The New Zealand Squadron was renamed No.75(NZ) Squadron in early 1940, becoming the first RAF Commonwealth Squadron of the Second World War. It was unusual for Bomber Command aircraft to carry nose artwork, but the distinctive bomb dropping soda syphon carried by R1162 ‘Y for Yorker’ has to be considered as amongst the most creative.
Corgi Aviation Archive AA34811 Vickers Wellington 1C, R1162 / AA-Y ‘Y for Yorker’, No.75 (New Zealand) Squadron, RAF Feltwell, Norfolk, 1941 ‘Soda Syphon Bomber’
Hobbymaster Special Release Swiss F18 Tiger Meet !
I have added the latest Hobby Master F-18C to the Flying Tigers website. Please see details below:_
Available to pre-order now !
Small production run scheduled for April 2017 release !
Hobbymaster 1/72nd scale
Swiss Air Force
“NATO Tiger Meet 2016”
Please click on the individual images to go straight to the model or CLICK HERE to go straight to the model !
New Range added to Flying Tigers
I have recently added a new range from True Scale Wings Collection in both 1/72nd scale and 1/200th scale. The Aircraft are from the Top Gun Movie, and the vehicles and crew figures go with them or indeed any aircraft models of the same scale. Please click on the individual images and links to go straight to the model of your choice. Or, if you feel the need…the need for speed, please take a closer look at the full range by CLICKING HERE.
